REEFE VSRE52-110 Variable Speed Multistage Pressure Pump

The REEFE VSRE52-110 is a variable speed multistage pressure pump designed to provide consistent water pressure while adjusting pump speed to match changing water demand.

The integrated variable speed drive allows the pump to respond automatically to water usage, helping maintain consistent pressure while reducing unnecessary energy consumption. The VSRE52-110 is suited to domestic and commercial water supply, irrigation, mains pressure boosting and stock watering applications.

With a rated flow of 55 LPM at 37m head and a maximum flow of 110 LPM, the VSRE52-110 is suitable for applications requiring reliable pressure across approximately 5–8 taps.

Applications

• Whole-house water supply
• Amenities blocks
• Hotels and restaurants
• Irrigation supply
• Mains pressure boosting
• Stock watering systems
• Domestic and commercial water supply

Features & Benefits

• Variable speed drive adjusts pump speed to changing water demand
• Designed to maintain consistent water pressure
• Efficient, energy-saving operation
• Multistage pump design
• Heavy-duty construction for extended service life
• Externally ventilated motor for improved heat management
• Automatic restart following loss of prime
• Certified to AS/NZS 4020 for potable water
• Supplied with a 2L pressure tank
• Built-in thermal overload protection
• Quick Plug connection
• Maximum water temperature of 35°C

Specifications

• Rated Flow: 55 LPM
• Rated Head: 37m
• Maximum Flow: 110 LPM
• Maximum Head: 52m
• Recommended Number of Taps: 5–8
• Motor Input (P1): 1.24kW
• Motor Output (P2): 0.8kW
• Voltage: 240V
• Current: 5.4A
• Variable Speed Drive: VSC1-7.5
• Inlet: 25mm / 1"
• Outlet: 25mm / 1"
• Pressure Tank: 2L
• Cable Length: 1.5m
• Weight: 13.55kg
• Dimensions (L × W × H): 372 × 260 × 519mm
• Maximum Water Temperature: 35°C
• Ingress Protection: IP44
• Insulation Class: F

Construction

• Stainless steel AISI 304 pump body and impeller
• Stainless steel AISI 416 shaft
• Carbon-graphite mechanical seal
• Built-in thermal overload protection
• 1.5m power cable
• Quick Plug connection
• 2L pressure tank
• IP44 protection
• Class F insulation

Product Details

• Model: VSRE52-110
• Product Number: 21644
